What is a U-value?

U-value tells us how well the different types of insulation material keep heat in or out of a wall, roof, window, and floor. The lower the U-value, the better the insulation and the less energy is needed to keep a building warm in winter or cool in summer, which is essential for meeting UK Building Regulations and reducing energy consumption.

Understanding how to calculate U-values and striving for low values in building design can ensure long-term comfort, sustainability, and financial savings.

How is U-value Measured?

The U-value is expressed in watts per square meter per degree Celsius (W/m²·K). This means that for every square meter of a material, the U-value indicates how many watts of heat are lost for each degree Celsius of temperature difference between the inside and outside of the building.

For example: A wall with a U-value of 0.20 W/m²·K will lose 0.20 watts of heat per square meter for each degree of temperature difference between inside and outside.

How to Calculate U-value

The U-value measures how effectively a building element, like a wall or roof, prevents heat loss. Lower U-values indicate better insulation. Here's how to calculate it:

1) Identify the Layers: Every wall or roof is made up of different materials, like brick, insulation, and plaster. You’ll need to know all the layers in the construction.

2) Measure the Thickness: Each material (brick, insulation, plaster) has a thickness. You’ll measure how thick each layer is in meters (m).

3) Find the Thermal Conductivity (k): Every material has a unique ability to conduct heat, called thermal conductivity (also known as λ). This is usually given in W/m·K (watts per meter per Kelvin). For example, some materials like brick or concrete conduct heat more easily than insulation materials like foam or fiberglass.

4) Calculate the R-Value for Each Layer: The R-value measures how resistant each layer is to heat flow. To calculate it, you use the formula:

Find the U-Value: The U-value is the inverse (opposite) of the total R-value. To calculate it, just do the following:

5) Sum Up the R-Values: Add the R-values for each layer together. This gives you the total thermal resistance of the entire wall or roof.

6) Find the U-Value: The U-value is the inverse (opposite) of the total R-value. To calculate it, just do the following:

Frequently Asked Questions

What would an architect or builder be calculating?

The architect calculates the U-value to ensure that the building has proper insulation and complies with energy efficiency regulations. A lower U-value indicates better insulation. The builder uses these calculations to select the correct materials and ensure walls or roofs meet the design and energy standards specified by the architect.

Is a lower U-value better?

Yes. A lower U-value means the material provides better insulation and reduces heat loss, improving energy efficiency. This can lower heating costs and reduce carbon emissions.
Example: A wall with a U-value of 0.20 W/m²·K is much more energy-efficient than one with 1.0 W/m²·K because it retains more heat during winter, reducing the need for extra heating.

What is a good or ideal U-value?

Ideal U-values in the UK vary depending on the building component and current regulations. As of 2024, recommended U-values are:

• Walls: 0.18 – 0.30 W/m²·K (depending on construction type and new build vs. refurbishment)
• Roofs: 0.13 – 0.18 W/m²·K
• Floors: 0.15 – 0.25 W/m²·K
• Windows: 1.4 – 1.6 W/m²·K or lower


These values ensure buildings meet minimum energy efficiency standards.

Why is U-value important?

U-value is a key measure of a building’s energy efficiency. Lower U-values offer several benefits:

• Reduced energy bills: Better insulation retains heat, lowering heating costs.
• Improved comfort: Consistent indoor temperatures and fewer drafts.
• Environmental benefits: Lower carbon emissions due to reduced energy consumption.


Ensuring low U-values in building components helps both the environment and your long-term energy costs.
